Specifications
Non-contractual photo. The difficulties in supplying due to the COVID-19 health crisis, impose certain modifications of technical specifications without notice to ensure the availability of the bicycles.
| CADRE |
Frame
ALLOY 6061 FRAME 27.5” INTEGRATED POWERTUBE VERTICAL INTERNAL CABLE ROUTING
Fork
ZOOM 188DS HLO 65MM |
| MOTORISATION |
Moteur
BOSCH PERFORMANCE LINE 250W/65Nm
Battery
BOSCH POWERTUBE 500Wh
Display
PURION |
| TRANSMISSION |
Rear derailleur
SHIMANO DEORE M5120 10v
Crankset
SUNN 38T
Cassette
SHIMANO DEORE M4100 10v 11-46
Handle
SHIMANO DEORE M6000 10v |
| FREINS |
Brake lever
SHIMANO MT410 160/160 |
| ROUES |
Wheel size
27,5''
Wheels
27.5x1.95
RIms
MACH1 TRAXX 21c 36T
Hubs
SHIMANO MT400/M4050 DISC
Tires
CONTINENTAL TERRA TRAIL 27.5x1.95 |
| COMPOSANTS |
Handlebar
AL 6061 620MM
Seat post
ERGOTEC SUSPENSION 27.2x350MM
Saddle
SELLE ROYAL LOOKIN GEL |
| ACCESSOIRES |
Accessories
GARDE-BOUE ALU, ECLAIRAGE SUPERNOVA V521S (AV) E3 (AR) BEQUILLE, RACK, SACOCHE, ANTI-VOL AXA, CHARGEUR 4A |
| DOCUMENTATION |
Geometry
Size | S | M | |
|---|---|---|---|
Seat Height | ST | 400 | 450 |
Top tube Length | TT | 580 | 600 |
Wheelbase | WB | 1111 | 1132 |
Head tube angle | HA | 69° | 69° |
Seat tube angle | SA | 72,5° | 72,5° |
Chainstay Length | RC | 465 | 465 |
Bottom bracket offset | BB | -60 | -60 |
Head tube Length | HT | 160 | 180 |
Sizes
A unique experience
Ideal for daily trips, the Bosch eBike System 2 combines power with a gentle ride. The Bosch Performance Line 250W/65Nm is the best motor in its category, promising simplified bike handling thanks to its light weight and small size.
With its Bosch Powertube 500Wh battery, you can go even farther while making the most of the smooth accelerations delivered by the Bosch drive unit.
