Specifications
Actual products may differ from photos. COVID-19 has led to supply chain issues with certain components, which sometimes compel us to adjust certain technical specifications without notice in order to ensure the availability of our bikes.
| FRAME |
Frame
INTEGRATED 531WH, ALLOY 6061DB, EDGE TUBING BOOST
Fork
SR SUNTOUR XCM34 130MM BOOST
Travel
130/130 |
| SYSTEM |
Moteur
SHIMANO EP6 85NM
Battery
SHIMANO EN 500 |
| TRANSMISSION |
Rear derailleur
SHIMANO DEORE 12V
Crankset
SHIMANO M600 170MM 34T
Cassette
SHIMANO DEORE 12V 10/51
Handle
SHIMANO DEORE 12V |
| BRAKES |
Brake lever
FORMULA CURA 2 180/180 |
| WHEELS |
Wheel size
29’’
Wheels
29x2.40
RIms
MACH1 TRUCKY 30 30MM 32T
Hubs
MOYEUX 6T SB BOOST
Tires
CHAOYANG PERSUADER TR 29X2,4 |
| COMPONENTS |
Handlebar
ALUMINIUM 760MM X 31,8 RISE15
Stem
ALUMINIUM 31,8X45MM
Seat post
BRUTE Dropper 130mm (S) / 150mm (M) / 170mm (L/XL)
Saddle
SUNN BY DDK |
| WEIGHT |
Weight
23,2 (Tubeless setup) |
| DOCUMENTATION |
Geometry
Size | S | M | L | |
|---|---|---|---|---|
Seat Height | ST | 400 | 450 | 500 |
Top tube Length | TT | 570 | 600 | 630 |
Wheelbase | WB | 1120 | 1150 | 1183 |
Steering angle | HA | 67,5° | 67,5° | 67,5° |
Seat tube angle | SA | 74° | 74° | 74° |
Chainstay Length | RC | 445 | 445 | 445 |
Bracket Height | BB | -55 | -55 | -55 |
Head tube Length | HT | 110 | 120 | 135 |
Standover | 795 | 830 | 860 | |
Reach | 390 | 415 | 440 | |
Stack | 635 | 645 | 660 | |
Fork | 540 | 540 | 540 |
