Specifications
Actual products may differ from photos. COVID-19 has led to supply chain issues with certain components, which sometimes compel us to adjust certain technical specifications without notice in order to ensure the availability of our bikes.
| FRAME |
Frame
GORDON INTEGRATED 630Wh 6061 EDGE TUBING, BOOST |
| SHOCK |
Fork
ROCKSHOX 35 SILVER R COIL, TAPERED, TA BOOST, 130MM
Travel
130/130
Shock
ROCKSHOX DELUXE SELECT+ RT 210x50 130MM |
| SYSTEM |
Moteur
SHIMANO STEPS E7000 250W/60Nm
Battery
SHIMANO BTE8036 630Wh |
| TRANSMISSION |
Rear derailleur
SHIMANO DEORE 10v
Crankset
SHIMANO E8000 170mm
Cassette
SHIMANO DEORE 11/42 10v
Handle
SHIMANO DEORE 10v |
| BRAKES |
Brake lever
FORMULA CURA 2 203/180 |
| WHEELS |
Wheel size
29’’
Wheels
29x2.35
RIms
MACH1 TRUCKY30 30c 32T
Hubs
MOYEUX BOOST 6T
Tires
AV/AR VEETIRES Snap Trail 29x2.35 |
| COMPONENTS |
Handlebar
VR 6061 760MM
Stem
EXT:75MM-6°-31.8
Seat post
SDG TELLIS DROPPER SEATPOST 31.6MM 125MM (S), 150(M/L)
Saddle
VR SPORT by DDK |
| WEIGHT |
Weight
21,45 |
| DOCUMENTATION |
Geometry
Size | S | M | L | |
|---|---|---|---|---|
Seat Height | ST | 400 | 450 | 500 |
Top tube Length | TT | 570 | 600 | 630 |
Wheelbase | WB | 1150 | 1180 | 1220 |
Steering angle | HA | 66,5° | 66,5° | 66,5° |
Seat tube angle | SA | 75° | 75° | 75° |
Chainstay Length | RC | 445 | 445 | 445 |
Bracket Height | BB | -25 | -25 | -25 |
Head tube Length | HT | 110 | 120 | 135 |
Standover | 815 | 830 | 860 | |
Reach | 405 | 435 | 460 | |
Stack | 615 | 625 | 640 | |
Fork | 551 | 551 | 551 |
