Specifications
Non-contractual photo. The difficulties in supplying due to the COVID-19 health crisis, impose certain modifications of technical specifications without notice to ensure the availability of the bicycles.
| CADRE |
Frame
ALLOY 6061 FRAME 27.5” INTEGRATED POWERTUBE VERTICAL INTERNAL CABLE ROUTING
Fork
ZOOM 188DS HLO 65MM |
| MOTORISATION |
Moteur
BOSCH PERFORMANCE 250W/65Nm
Battery
BOSCH POWERTUBE 500Wh
Display
PURION |
| TRANSMISSION |
Crankset
SUNN / GATES 50T
Cassette
GATES 22T
Courroie
CARBON GATES BELT DRIVE
Handle
SHIMANO NEXUS SL-7550 7v |
| FREINS |
Brake lever
SHIMANO MT200 160/160 |
| ROUES |
Wheel size
27,5''
Wheels
27.5x1.95
RIms
MACH1 TRAXX DISC 21c 36T
Hubs
SHIMANO MT400 NEXUS 7 SPD, DISC
Tires
CONTINENTAL TERRA TRAIL 27.5x1.95 |
| COMPOSANTS |
Handlebar
AL 6061 620MM
Stem
EXT:90MM-25°-31.8
Seat post
SR SUNTOUR NCX SUSPENSION 27.2x350MM
Saddle
SELLE ROYAL LOOKIN 3D |
| POIDS |
Weight
24,57 |
| DOCUMENTATION |
Geometry
Size | S | M | |
|---|---|---|---|
Seat Height | ST | 400 | 450 |
Top tube Length | TT | 580 | 600 |
Wheelbase | WB | 1111 | 1132 |
Head tube angle | HA | 69° | 69° |
Seat tube angle | SA | 72,5° | 72,5° |
Chainstay Length | RC | 465 | 465 |
Bottom bracket offset | BB | -60 | -60 |
Head tube Length | HT | 160 | 180 |
Sizes
Quiet and clean
Our Rely electric bike has a Gates carbon belt drive. Sturdy and clean, it requires almost no upkeep, so you can forget about great stains and ride with complete peace of mind.
A unique experience
Ideal for daily trips, the Bosch eBike System 2 combines power with a gentle ride. The Bosch Performance Line 250W/65Nm is the best motor in its category, promising simplified bike handling thanks to its light weight and small size.
With its Bosch Powertube 500Wh battery, you can go even farther while making the most of the smooth accelerations delivered by the Bosch drive unit.
