Specifications
Actual products may differ from photos. COVID-19 has led to supply chain issues with certain components, which sometimes compel us to adjust certain technical specifications without notice in order to ensure the availability of our bikes.
| FRAME |
Frame
ALLOY 6069 EDGE TUBING
Fork
FULL CARBON HM |
| TRANSMISSION |
Rear derailleur
SHIMANO SORA R3000 2x9v
Crankset
FSA MEGAEXO 46/30
Cassette
SHIMANO HG400 9v 11-34
Handle
SHIMANO SORA ST-R3000 2x9v |
| BRAKES |
Brake lever
SHIMANO MECHANICAL DISC BRAKE RS305 160/140 |
| WHEELS |
Wheel size
700
Wheels
700x37
RIms
MACH1 ER20 DISC 700x19c 32T
Hubs
SHIMANO RS470 CL
Tires
GRAVEL 700x40 |
| COMPONENTS |
Handlebar
VR AL GRAVEL 16° 400MM (S/M), 420MM (L/XL)
Stem
STEM 75MM (S/M), 90MM (L/XL
Seat post
KALLOY AL6061 27.2x350MM
Saddle
SUNN DDK SPORT |
| DOCUMENTATION |
Geometry
Size | S | M | L | XL | |
|---|---|---|---|---|---|
Seat Height | ST | 400 | 450 | 500 | 550 |
Top tube Length | TT | 530 | 550 | 570 | 590 |
Wheelbase | WB | 1014 | 1030 | 1046 | 1062 |
Steering angle | HA | 70° | 70,5° | 71° | 71,5° |
Seat tube angle | SA | 73,5° | 73,5° | 73,5° | 73,5° |
Chainstay Length | RC | 425 | 425 | 425 | 425 |
Bracket Height | BB | -70 | -70 | -70 | -70 |
Head tube Length | HT | 120 | 140 | 160 | 180 |
Standover | 725 | 762 | 800 | 832 | |
Reach | 367 | 381 | 395 | 409 | |
Stack | 549 | 570 | 591 | 612 | |
Fork | 408 | 408 | 408 | 408 |
Sizes
